Tare Weight :

5200kg

Trailer Payload

40000kg

Overall Length

12400mm

Overall Width

2500mm

Overall Height

1650mm

Wheel track

1830mm

Wheelbase

7545mm 1310mm 1310mm

40ft Container Semi Trailer Specification:

Main Frame

Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes

500mm Height, Top Flange 14mm; Middle Flange 6mm; Bottom Flange 16mm

Axle

Three units FUWA/HUAJING Brand 13T Axle

Suspension

China brand mechanical suspension, American design

Leaf Spring

Six sets of reliable China brand leaf spring, 90*16mm or 100*12mm

King Pin

one unit of 3.5" bolt-in kingpin, standard

Landing Gear

28 T

Wheel Rim

12 units of 9.0*22.5 wheel rim

Tire

12 units tire

Twist Lock

Twelve nos. four nos are fasten mode, eight nos are up-down mode, of ISO twist lock for 2x20ft or1x40ft container, central locks can be laid down.

Pneumatic Braking System

Two units of WABCO RE 6 relay valve; four units of T30/30 spring brake chamber; two units T30 brake chamber, two units of reliable local brand 40L air tank; two units of reliable local brand standard coppery air-connector.

Electrical System

One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; two sets of reliable, local brand standard rear light, turn light, rear reflector, side light, side reflector etc.

Painting

Sand blasting before painting; one coats of primer, anti-corrosion; two coat of finish painting; colour advised by client

Accessory

One box with a set of standard trailer tool
